UBP™ Series

UBP2K Pro

UBP™ Series – Entry Level Cost-Effective Power System

The Unicell Boost Pulsar UBP1K-BLE is a robust energy storage solution, providing 2000Wh capacity and a 1000W output, suitable for higher power demands. At 20 kg, it incorporates protections against overcharge, over-discharge, overcurrent, and short circuits. With a 90% AC efficiency and pure sine wave output, it delivers reliable power for home emergency backups, outdoor adventures, and mobile workstations. Whether for off-grid use, camping, or disaster relief, this system offers *cost-effective, long-lasting power.

Powerful Boost Technology Used

Upgrade Metal Case Version

Kernel Parameter

  • Capacity: 2000Wh
  • Rated Output Power: 1000W
  • Mppt Input Vltage: 11~55V/ 550W Max.
  • Fast Charging: AC around 3.6hours,AC around 2hours

Advantages:

  • AC Charge/Discharge Power:1000W for the latest version.

  • PV Charging Power: 5500W for the latest version , with universal compatibility for commercial PV panels.

  • Low Noise Level: ≤50dB for the latest version .

  • Premium Metal Housing: Corrosion-resistant, anti-aging, and sleek high-end design.

  • Rich Interfaces: Equipped with a 5V USB output, compatible with our proprietary display screen.

  • MC4 PV Connector: Plug-and-play design, universally compatible with all standard commercial solar panels.

  • Dual Installation Modes: Portable or wall-mountable, suitable for various application scenarios.

  • Removable Dust Filter: Washable design extends service life.

  • Easy After-Sales Maintenance: Optimized structure for convenient servicing.

  • Super Cost-effective and affordable

  • Powerful AC / Solar Charging

  • Small In Size and Light Weight

  • Emergency Backup Power

  • Remote Monitoring and PAYG

Reliable in performance;

  • Attractive in appearance;
  • Multiple work modes, suitable for many scenarios: Camping, Traveling, RV, Emergency, etc.
  • Compact size;
  • Easy to operate;
  • Convenient to carry;
  • High energy density
  • Space saving ( Laid flat or hung on the wall, not upright.)

Available to registered users after login/registration is enabled.

Product Properties

PropertyValue
Solar Charge Till Full TimeEstimated time 3.6
AC Charge Till Full TimeEstimated time 2
Energy Capacity2000
Maximum Output Power1000
Input Max. PV Power550
Input MPPT Range11~55V/ 300W Max.
Rated Input Voltage230
Input Voltage Range90~280Vac+5Vac
Input Power Factor>0.95
Rated Output Voltage230Vac ± 5Vac
Output Power Factor≥0.99
Maximum Charging Power1000
Overload capacityCP 500W Latch output @ <170Vac
Charging PortPV MC4/AC(Pin type)
DisCharging PortUniversal AC socket x 2PCS and USB Phone Charging 5v5W x1PCS
Product Standard Configuration1xUBP1K Pro, 1xAC Charging Cable,1xUse Manual, Wall Mount
Package Dimension540*375*225
Package Weight22
Solar PanelOptions (Foldable Solar Panel or Crystalline Silicon Solar Panel)

Items Included
